ROG STRIX Z370-I GAMING specications summary
CPU
Intel
®
Socket 1151 for 8th Generation Core™ Processors
Supports 14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset
Intel
®
Z370 Chipset
Memory
2 x DIMM, max. 32GB DDR4 4333+ (O.C.) / 4266 (O.C.) / 4133(O.C.)
/ 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) /
3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) /
2800(O.C.) / 2666(O.C.) / 2400 / 2133 MHz Non-ECC, Un-buffered
Memory
Dual channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)*
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
Please refer to Memory QVL(Qualied Vendors List) for details.
Expansion slots
1 x PCIe 3.0 x16 slot*
* For 2 or 3 Intel
®
SSDs on CPU support, install a Hyper M.2 X16 card (sold
separately) into the PCIeX16 slot, and enable this card under BIOS settings.
VGA
Integrated Graphics Processor- Intel
®
HD Graphics support
Multi-VGA output support: DisplayPort/HDMI ports
Supports DisplayPort 1.2* with max. resolution 4096 x 2304@60Hz
Supports HDMI 1.4b with max. resolution 4096 x 2160@24Hz
Supports Intel
®
InTru™ 3D/Quick Sync Video/Clear Video HD Technology/
Insider™
Maximum shared memory of 1024MB
* DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor daisy chain
up to 3 displays.
Storage
Intel
®
Z370 Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage
Technology support
- 4 x SATA 6Gb/s ports
- 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280 storage devices
support (both SATA & PCIE 3.0 x 4 modes)*
- 1 x M.2_2 Socket 3 with M key, type 2242/2260/2280 storage devices
support (PCIE 3.0 x 4 mode)*
- Ready for Intel
®
Optane Memory**
* For a 2242 storage device, use the bundled 2242 mounting kit.
** Intel
®
Optane Technology only supported when using 8th Generation Intel
®
Processors. Before using Intel
®
Optane memory modules, ensure that you have
updated your motherboard drivers and BIOS to the latest version from ASUS
support website.
LAN
Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated Media
Access Controller (MAC) and physical layer (PHY)
Anti-surge LANGuard
ROG GameFirst Technology
(continued on the next page)
