Инструкция по эксплуатации Страница: 44

Asus ROG STRIX Z370-I GAMING [44/98] M installation

2-12

Chapter 2: Basic Installation

Chapter 2

2.1.9 M.2 installation

The M.2 SSD is purchased separately.
