Asus ROG STRIX Z370-I GAMING [35/98] Cpu installation

ASUS ROG STRIX Z370-I GAMING

2-3

Chapter 2

2.1.2 CPU installation

Ensure that you install the correct CPU designed for LGA1151 socket only. DO NOT install

a CPU designed for LGA1155 and LGA1156 sockets on the LGA1151 socket.

Top of CPU

Bottom of CPU
