Asus ROG STRIX Z370-I GAMING [34/98] Chapter 2

2-2

Chapter 2: Basic Installation

Chapter 2

3. Place four (4) screws into the holes indicated by circles to secure the motherboard to

the chassis.

DO NOT overtighten the screws! Doing so can damage the motherboard.
