xi
(continued on the next page)
ROG STRIX Z370-I GAMING specications summary
ASUS Special
Features
Fan Xpert 4
- featuring Fan Auto Tuning function and multiple thermistors selection
for optimized system cooling control
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
ASUS Q-Design
- Q-Shield
- Q-LED (CPU, DRAM, VGA, Boot Device LED)
- Q-Slot
- Q-DIMM
Gamer’s Guardian
- SafeSlot
- DIGI+ VRM
- DRAM Overcurrent Protection
- ESD Guards on LAN, Audio, and USB ports
- Highly Durable Components
- Stainless Steel Back I/O
ASUS Exclusive Features
- AURA Lighting Control
- AI Suite 3
- AI Charger
Internal I/O
connectors
1 x USB 3.1 Gen2 front panel connector
1 x USB 3.1 Gen1 connector supports additional 2 x USB 3.1 Gen1 ports
1 x USB 2.0 connector supports additional 2 x USB 2.0 ports
4 x SATA 6Gb/s connectors
1 x 4-Pin CPU fan connector
1 x 4-Pin Chassis fan connector
1 x 4-Pin AIO_PUMP connector
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V power connector
1 x M.2_1 Socket 3 for M Key, type 2242/2260/2280 storage devices support
( Supports PCIE 3.0 x 4 and SATA modes)*
1 x M.2_2 Socket 3 for M Key, type 2242/2260/2280 storage devices support
(Supports PCIE mode only)*
1 x Front panel audio connector (AAFP)
1 x Addressable Header
1 x System panel connector
1 x Thermal sensor connector
1 x Clear CMOS jumper (2-pin)
* For a 2242 storage device, use the bundled 2242 mounting kit.
