2-12
Chapter 2: Basic Installation
Chapter 2
2.2 BIOS update utility
USB BIOS Flashback
USBBIOSFlashbackallowsyoutoeasilyupdatetheBIOSwithoutenteringtheexisting
BIOS or operating system. Simply insert a USB storage device to the USB port (the USB port
holemarkedingreenontheI/Oshield)thenpresstheUSBBIOSFlashbackbuttonforthree
seconds to automatically update the BIOS.
TouseUSBBIOSFlashback:
1. Download the latest BIOS from the support site at www.asus.com/support/ and save it
to as USB storage device.
• WerecommendyoutouseaUSB2.0storagedevicetosavethelatestBIOSversion
for better compatibility and stability.
• WhendownloadingorupdatingtheBIOSle,renameitasP10SMWSI.CAP for this
motherboard.
2. InserttheUSBstoragedevicetotheUSBFlashbackport.
Refer to section 2.3.1 Rear I/O connection for the location of the USB port that supports
USBBIOSFlashback.
3. Shut down your computer.
4. PresstheBIOSFlashbackbuttonforthreesecondsuntiltheFlashbackLEDblinks
threetimes,indicatingthattheBIOSFlashbackfunctionisworking.
• Donotunplugportabledisk,powersystem,orpresstheCLR_CMOSbuttonwhile
BIOS update is ongoing, otherwise update will be interrupted. In case of interruption,
please follow the steps again.
• Ifthelightashesforvesecondsandturnsintoasolidlight,thismeansthat
theBIOSFlashbackisnotoperatingproperly.Thismaybecausedbyimproper
installationoftheUSBstoragedeviceandlename/leformaterror.Ifthisscenario
happens, please restart the system to turn off the light.
• UpdatingBIOSmayhaverisks.IftheBIOSprogramisdamagedduringtheprocess
and results to the system’s failure to boot up, please contact your local ASUS Service
Center.
For more BIOS update utilities in BIOS setup, refer to the section 3.1 Managing and
updating your BIOSinChapter3.
USB BIOS Flashback port BIOS Flashback button
5. Waituntilthelightgoesout,indicatingthattheBIOSupdatingprocessiscompleted.
