ix
(continued on the next page)
P10S-M WS Series specifications summary
Model Name P10S-M WS/IPMI-O P10S-M WS
CPU
LGA1151 socket for 6th Generation Intel
®
Core™ i7/ i5/ i3/Pentium
®
/Celeron
®
/
Xeon
®
E3-1200 v5 Processor Family Processors
Supports 14 nm CPU
Supports Intel
®
Turbo Boost Technology
** Refer to www.asus.com for Intel
®
CPU support list
Chipset
Intel
®
C236 Chipset
Memory
4 x DIMM, Max 64GB, DDR4 2133 MHz, ECC/ non-ECC UDIMM
Dual channel memory architecture
** Refer to www.asus.com for the Memory QVL(Qualified Vendors List)
Expansion slots
PCIEX1_1:
PCI-E x1 slot, x1 Gen3 Link, from PCH
PCIEX16_1:
PCI-E x16 slot, x16 Gen3 Link
PCIEX8_1:
PCI-E x8 slot, x4 Gen3 Link, from PCH
VGA Output
Integrated Graphics Processor x 1
Multi-VGA output support: DVI-D/
HDMI/DisplayPort
- Supports DVI-D with Max
resolution 1920 x 1200@60 Hz
- Supports HDMI with Max
resolution 4096 x 2160@60/24
Hz
- Supports DisplayPort with Max
resolution 4096 x 2304@60 Hz
- Supports Intel
®
HD Graphics,
InTru™ 3D, Quick Sync Video,
Clear Video HD Technology,
Insider™
- Maximum shared memory of
512MB
AST2400 with 32MB VRAM
Integrated Graphics Processor x 1
Multi-VGA output support: DVI-D/
HDMI/DisplayPort
- Supports DVI-D with Max
resolution 1920 x 1200@60 Hz
- Supports HDMI with Max
resolution 4096 x 2160@60/24
Hz
- Supports DisplayPort with Max
resolution 4096 x 2304@60 Hz
- Supports Intel
®
HD Graphics,
InTru™ 3D, Quick Sync Video,
Clear Video HD Technology,
Insider™
- Maximum shared memory of
512MB
Storage
Intel
®
C236 Chipset:
8 x SATA 6Gb/s ports or 7 x SATA 6Gb/s with 1 x M.2 (SATA 6Gb/s & PCI-E
Gen3 x4 link, NGFF 22110/2280/2260/2242)
Intel
®
RSTe (Windows & Linux)
(Support software RAID 0, 1, 10 & 5)
LAN
2 x Intel
®
I210 GbE LAN
1 x Mgmt LAN
(Support teaming function)
2 x Intel
®
I210 GbE LAN
(Support teaming function)
USB
Intel
®
C236 Chipset:
- 4 x USB 2.0 ports (2 ports at front panel, 2 ports at back panel)
- 6 x USB 3.0 ports (4 ports at front panel, 2 ports at back panel)
