3-30
Chapter 3: BIOS Setup
Chapter 3
SATA Port 1 / SATA Port 2 / SATA Port 3 / SATA Port 4 / SATA Port 5 /
SATA Port 6 / SATA Port 7 / SATA Port 8
Port 1 / Port 2 / Port 3 / Port 4 / Port 5 / Port 6 / Port 7 / Port 8 [Enabled]
Allows you to enable or disable the SATA port.
Congurationoptions:[Disabled][Enabled]
Mechanical Presence Switch [Enabled]
Allows control of reporting if this port has a Mechanical Presence Switch.
Congurationoptions:[Disabled][Enabled]
Spin Up Device [Disabled]
Selecting[Enabled]willstartaCOMERSETinitializationsequencetothedeviceonan
edge detect from 0 to 1.
Congurationoptions:[Disabled][Enabled]
SATA Device Type [Hard Disk Drive]
AllowsyoutosetwhethertheSATAportisconnectedtoSolidStateDriveorHardDisk
Drive.
Congurationoptions:[HardDiskDrive][SolidStateDrive]
Device Sleep [Disabled]
Allows you to enable or disable the mSata for RTD3.
ConifgurationOptions:[Disabled][Enabled]
SATA DEVSLEP Idle Timeout Config [Disabled]
AllowsyoutoenableordisableSATADTIOCong.
Congurationoptions:[Disabled][Enabled]
IRRT Only on eSATA [Enabled]
[Disabled] AnyRAIDvolumecanspaninternalandeSATAdrives.
[Enabled] OnlyIRRTvolumescanspaninternalandeSATAdrives.
Smart Response Technology [Enabled]
Allows you to enable or disable the Smart Response Technology.
Congurationoptions:[Disabled][Enabled]
OROM UI Normal Delay [4 sec]
Allows you to select the delay time of the OROM UI Splash Screen in a normal status.
Congurationoptions:[2sec][4sec][6sec][8sec]
RST Force Form [Disabled]
Allows you to enable or disable Form for Intel Rapid Storage Technology.
Congurationoptions:[Disabled][Enabled]
