3. Projection of Images (Basic Operation)

3-6.

Turning on/off the lamp with the projector turned on

3-6-1. Turning off the lamp

Press the LAMP ON/OFF button on the control panel for ﬁve seconds or longer.

LAMP MENU ENTER

DOUSER

KEY

LOCK

EXIT

IMB

3-6-2. Turning on the lamp

Press the LAMP ON/OFF button on the control panel for ﬁve seconds or longer.
