Nec NC3200S [50/70] Maintenance of your projector
![Nec NC3200S [50/70] Maintenance of your projector](/views2/1375701/page50/bg32.png)
50
5. Maintenance of Your Projector
3
Replace with new air filters.
Look for an arrow indicating the installation direction on the side of the air filter. Place the filter so that the arrow is
pointing down at the projector.
AI
R
FL
OW
AIR
F
LOW
4
Mount the filter cover.
Align two fasteners on the filter cover to the holes on the projector, and push in until the latch clicks.
Latch
5
Repeat Step 2 to 4 to replace one more air filter.
This completes replacement of the air filters for the projector air inlets on the side.
