36
4. Using Menus
4-2. Table of adjustment menus
Menus in parentheses are menus for our service personnel. Normally, these menus cannot be used.
Main menu Submenu Description
Reference
page
Title Select “Title Memory Name” Selects the title of the signal to be projected. 37
TEST Pattern Selects the test pattern to be projected. 37
Configuration Lamp Setup Adjust Adjusts lamp brightness. 38
Feedback Sets the lamp brightness constant mode that uses a brightness sensor. 38
Lens Control Lens Position Adjusts the position of the projected screen. 38
Focus Zoom Fine tunes the size and focus of the projected screen. 38
(Setup) Douser Mode Selects whether to use the douser (screen mute) when switching
signals.
-
PowerOn Douser Sets the douser status (ON/OFF) when the projector is turned on. -
Turret Controls the turret mounted with an anamorphic lens (or wide converter
lens).
-
Panel Key Lock Locks the buttons on the projector’s control panel so that they cannot
be operated.
-
Auto Key Lock Enables or disables Auto Key Lock. -
3D Connector Sets the signal input terminal for a 3D image system (3D terminal or
GPI/O terminal).
-
FactoryDefault Returns the settings to their default values. Selects between preset
buttons and titles only, LAN settings only and all settings.
-
(Installation) (Option Slot) Configures the device installed in slot A and slot B (only when the
projector is in standby mode).
-
Image Orient Selects the projection method (front/rear). -
Lens Center Moves the lens shift position to the center. -
MMS Select Selects the multi-media switcher (MMS) to connect. -
Baudrate Sets the PC control connector (RS-232C) data transmission speed
(bps).
-
Date/Time Sets the date and time on the projector. -
(New Bulb) Resets the lamp bulb usage time and selects or edits new entries (only
when the projector is in standby mode).
-
(Bulb Warning) Sets the lamp bulb warning time (only when the projector is in standby
mode).
-
(New Lamp house) Resets the lamp house usage time, and makes settings or selects
modes (only when the projector is in standby mode).
-
Bulb Alignment Sets the lamp bulb alignment. -
Usage Reset Initializes the usage time of the fan and air filter. -
NewRouterSetup Sets the router with the default settings when the router built-in the
projector has been replaced.
-
(Memory) Lamp Saves the current lamp setting. -
Lens Saves the current lens setting. -
(Title Setup) Preset Button Preset Button 1-8 Sets the title to be assigned to the preset buttons (<1> to <8> buttons). 39
Information Lamp Output Displays the lamp output setting. 39
Bulb Type [A] Displays the registered name and the maximum/minimum current
setting of the currently used lamp bulb.
39
Bulb Type [W] Displays the registered name and the lamp rated output (kW) of the
currently used lamp bulb.
39
Bulb Type [H]
Displays the registered name and the lamp bulb warning time (Bulb
Warning Time) setting of the currently used lamp bulb.
39
Preset Button Preset Button 1-8 Displays the titles which are assigned to the preset buttons (<1> to
<8> buttons).
40
Usage Displays the usage time of the projector, lamp bulb, lamp house, bulb
warning, fan, and air filter.
40
Error Code Displays the currently occurring error. 40
Version System Displays the model and version (BIOS, firmware, data, and serial No.)
of the projector.
41
SIB Displays the version of the signal input board (NC-80LB01). 41
IMB Displays the version of the media block (IMB). 41
MMS(Built-in) Displays the version of the built-in multi-media switcher (MMS). (BIOS,
Firmware, Data, FPGA, and Serial No.)
41
IP Address System Displays the IP address of the projector. 42
Setup Date Displays the date when the projector was set up (starting date of the
warranty period).
42
Option Status Displays the link status of the device mounted in slot A and slot B, and
the projector.
42
