1. What’s in the Box? and the Names of the Projector Parts
1-2. What’s in the Box?
Check the content of the accessories.
1-2-1. Accessories for the projector (NS3200S)
NC3200S projector
Attachment for lamp x 1
Sheet of title labels (for 20 labels) x 2
Cover key x 2
Lamp door key x 2
CD-ROM (User’s Manual)
Lens holder (NC-PH01)
Small iris x 1
Exhaust outlet protective sheet x 1
Exhaust outlet protective sheet fastening band x 4
Air inlet cover x 2
Retainer for lamp power AC power cable x 1
Important Information x 1
