Nec NC3200S [34/70] Using menus
![Nec NC3200S [34/70] Using menus](/views2/1375701/page34/bg22.png)
34
4. Using Menus
6
Press the DOWN button.
The submenu “BIOS” another rank lower than “System” is displayed.
7
Press the LEFT/RIGHT button to select the submenu “Data.”
At each press of the LEFT/RIGHT button, the display will cycle as “BIOS” ←→ “Firmware” ←→ “Data” ←→ “Serial
No.” ←→ “Model,” and each version information is displayed.
8
Press the UP button several times.
At each press of the UP button, the display will return to a menu one level above.
