1. What’s in the Box? and the Names of the Projector Parts
1-2-2. Accessories for the lamp power supply (NC-32PS01)
Lamp power supply (NC-32PS01) (with the power cable)
Dedicated
interface cable x 1
TIP
In the event that you did not receive all of the accessories outlined above, or some are damaged, contact your
dealer/distributor.
Differs slightly from the drawings in this manual, but there is no problem in actual use.
