68
6. Appendix
6-7. Related products list
Product name Model name
Lens Zoom lens 1.25 to 1.45 L2K-12ZM
Zoom lens 1.45 to 1.8 L2K-14ZM
Zoom lens 1.44 to 2.05 NC-50LS14Z
Zoom lens 1.6 to 2.4 NC-50LS16Z
Zoom lens 1.8 to 2.4 L2K-18ZM
Zoom lens 1.8 to 3.0 NC-50LS18Z
Zoom lens 2.2 to 3.0 L2K-22ZM
Zoom lens 2.15 to 3.6 NC-50LS21Z
Zoom lens 3.0 to 4.3 L2K-30ZM
Wide Converter Lens X 1.26 NC-80LS13F
Anamorphic lens motorized turret Anamorphic turret NC-AT02
Lamp 4.5 kW Lamp NC-LP4501
6.0 kW Lamp NC-LP6001
7.0 kW Lamp NC-55LP701
Dedicated base Pedestal NC-PD02
Replacement air filter Air Filter (For the lamp) NC-80AF01
Air Filter (For the projector) NC-80AF02
Built-in type multi-media switcher Built-in type Multi-Media Switcher MM3000B
Interface board (DVI HDCP) DVI (HDCP) Input Board MM-70DV01
Interface board (SDI) SDI Input Board MM-SDI
Interface board (RGB) Analogue RGB Input Board MM-RGB
Interface board (VIDEO) Video Input Board MM-VIDEO
