8023 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 16 of 61
3 BEFORE OPERATION
You receive your Speedy 400 packed in a wooden crate, which contains the laser and
additional accessories.
A suitable fork-lift is required to unload from the courier vehicle and lift the machine off its
pallet.
A powered screwdriver with cross-head bit is recommended for dismantling the wooden
crate.
If possible keep the packaging in case the machine ever needs to be relocated or shipped
for any reason.
3.1 Forklift transport
If possible keep the packaging in case the machine ever needs to be relocated
or shipped for any reason.
Dispose all waste according to the applicable waste disposal law.
Lifting points
The machine may only be lifted
and transported:
Under the guidance of a
2
nd
person, and
At the points identified.
