Trotec Speedy 500 [7/61] Technical data device specification
![Trotec Speedy 500 [7/61] Technical data device specification](/views2/1404710/page7/bg7.png)
8023 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 7 of 61
1.4 Technical Data / Device Specification
Mechanics
Working area
1000 x 610 mm (39 x 24 in)
Loading area
Up to 1090 x 690 mm x 305 mm (42.9 x 27.1 x 12 in) - depending on working
table
Up to 1045 x ? x 185 mm (41 x ? x 7.2 in) - depending on working table, with
pass-trough
Max. height of work piece
Up to 305 mm (12 in) depending on table configuration and lens
Work piece table
Flexible table design: engraving, vacuum and cutting table; aluminum grid;
computer controlled and programmable servo z-axis
Speed of motion system
355 cm/sec. (139 in/sec)
Acceleration
4 g
Motor
Brushless DC servomotor
Encoder
Increment measuring system
Lenses
1.5", 2.0" (standard); 2.5", 4.0" (optional)
Addressable accuracy
5µm
Repeatability
< 0,015 mm (0.0006 in)
Accuracy to size of parts
According to material an process
Maximum material load
20 kgs (55 lbs) area load over the whole working area
Exhaust
Table exhaust via rear of engraving cabinet
Standard Features
Ergonomic access to working area, electro-optic autofocus, laserpointer
(655nm, <0,99mWcw), coaxial air assist (without pump), 2.0" lens (can be
exchanged free of charge with 1.5", 2.5" or 4.0" lens), trolley base, one working
table of choice (vacuum or cutting table, black aluminum grid or engraving
table), USB connection, JobControl X Expert software
Options
Harsh environment protection kit, Pass-through opening (back), rotary
attachment, air assist including compressor, temperature sensor, laser power
upgrade, vacuum table, engraving table, black aluminum grid, cutting table
(lamellas), honeycomb table, white plastic cutting grid
Options
Pass-through opening (back)
Height/width: 185 x 1045 mm (7.2 x 41 in)
maximum material height 185 mm (7.2 in)
Rotary attachment
Cones, roller or combined version; tiltable
JobControl® Vision camera
Registration marks and compensation system "JobControl® Vision";
max. working area: 1000 x 610 mm (39.3 x 24 in)
Engraving via JobControl with camera attached: 975 x 600 mm (38.3 x 23.6 in)
Vacuum table
Vacuum effect for thin or corrugated materials
Honeycomb table
In combination with vacuum table
Black aluminum grid
For reflection-free cutting of small objects
Cutting table
Removable aluminum lamellas
Control System
Software
JobControl X Expert
Laser power
Adjustable 0 - 100%
Interface hardware
USB, RS-232 (RS-232 mandatory for TroCAM and JobControl® Vision)
Interface software
ASCII, HPGL, JobContro
