8023 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 24 of 61
4 OPERATION
4.1 Machine view and connections front
1
Top lid
6
Vaccuum table connection
2
Service access panel
7
Dust Protection (optional)
3
Connection Socket for Rotary
8
Keypad
4
Working table
9
X-axis
5
Front lid
1
2
9
3
4
5
7
6
8
