3.5 Exhaust System - Requirements

To guarantee the right ventilation during the engraving and cutting process, an

exhaust system with a minimum suction power of 300 m/h is required.

The device must be equipped with a fine dust filter as well as an activated

carbon filter (neutralization of smells).

Trotec advises to use the Atmos Duo Plus.

Connection - see section 3.7.3 Connecting the Exhaust System.

Do not start the machine without an adequate exhaust system.

3.6 Computer - Requirements

The following recommendation represents the minimum requirements.

When using a more powerful computer the graphics are generated and displayed faster and

the computing times and the data transfer to the laser are reduced. To use the newest

software version, you might have to abide other requirements.

 Windows 7 32/64-bit or

Windows Vista 32/64-bit (with Service Pack 1 or later) or

Windows XP 32/64-bit (with Service Pack 2 or later)

 Microsoft .NET framework 3.5

 Adobe Reader 9.0 or later

 Local administrative privileges (for required software installations)

 GHz processor or faster

 GB RAM or greater (Windows 7, Windows Vista) or

 1 GB RAM or greater (Windows XP)

 80 GB hard drive or larger

 1024 x 768 resolution monitor or greater

 true color graphics card (24-bit color depth)

 1 free USB interface

 CD-ROM drive

 Mouse
