8023 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 8 of 61
Laser Equipment
Laser tube
Sealed off CO2 Laser, maintenance-free,
Laser Power 40 - 120 W, air-cooled
Wavelength
10,6m
Dimensions
Width/depth/height
1400 x 950 x 1070 mm / 55 x 37.4 x 42.1 inch
Weight
Approx. 350 kgs / 770 lbs (depending on laser power)
Ambient conditions
Mandatory ambient temperature +15 to +25 C or 59 to 77 F
Humidity 40% to max. 70%, not condensing
Dust free environment (2nd degree according to IEC 60947-1)
Laser Safety
Laser class
CDRH laser safety; CE tested
Laser class 2 (Laser class 4 when operated with pass-through opening)
Interlock
Duplicate interlock safety system
Loading lid
Front side loading lid
Exhaust
Required
Atmos Duo Plus or equivalent
Electrical Equipment
Power consumption
1,4 kW (60 W laser tube)
Subject to change without notice. Errors and omissions excepted. March 2012
