9. Now switch on the laser and wait until the referencing is finished. Position the working

head over the object at the position, where you want to engrave. Now focus the object with

the focus tool. If the object slopes too much in the area to be engraved, the rotary engraving

attachment can be tilted, so that the surface of the object is running again parallel with the

X axis of the motion system. To do this, lift the right-hand side of the rotary engraving

attachment and place a wedge under it. Take care not to lift the rotary engraving attachment

too high, as it can touch the lens holder.

Engraving:

Additionaly consult the Software Manual for further information about the engraving process.

9. Generate a graphic with the help of your graphics software. The size is not important,

as the graphic can be adjusted to the dimensions of the work piece by the printer

driver.

10. Then perform the settings for size and orientation in the JobControl under "Plate,

Setup Plate" and, if necessary, select the engraving material. Please note especially,

that you can determine the orientation of the graphic on the object with "Job

Orientation”.

11. In the "Options" menu of the JobControl select "Rotary Engraving Attachment" and

enter the diameter of the object.

12. Double-click on the previously generated job in the waiting list to place it on the plate.

13. Use the mouse to drag the job to the position of the plate, at which the desired

engraving area is located on the object. Use the rulers in the machine and in

JobControl for orientation and move the lens holder directly over the desired position,

after you have connected the computer with the laser, and position the job on the

screen according to the position of the lens.

14. Establish the connection to the laser.

15. Switch on the exhaust system (only necessary if you do not use an original Trotec

exhaust system).

16. If you use a machine type with a water cooled laser tube, switch on the cooling

system before switching on the laser.

17. Activate the START button in the Engraver Control of the JobControl and start the

engraving process.
