6. Hold the lens assembly by its edge with a lens cleaning tissue and use a drop of lens

cleaning liquid from the little bottle which you received as an accessory delivered with the

laser. While holding the lens on an angle, flush both surfaces of the lens, to wash away

coarse soiling.

7. Put the lens on a clean lens cleaning tissue. Put some lens cleaning liquid on one

side of the lens. Leave the liquid to take effect for approximately one minute and then gently

wipe it away with lens cleaning tissues soaked with lens cleaning liquid.

8. Finally, dry this side of the lens with dry lens cleaning tissues and repeat the cleaning

process on the other side of the lens.

Never use a cleaning tissue twice. Dust accumulated in the cleaning tissue

could scratch the lens surface.

9. Examine the lens. If it is still soiled, repeat the cleaning process until the lens is clean.

10. Carefully insert the lens holder with lens into the working head.

The rounded side (= convex) of the lens is facing upwards. This is guaranteed

by the design of the lens holder.

11. Fix the lens holder carefully with the fixing ring.
