![Airwell SLS 3402 [27/77] Operation](/views2/1409210/page27/bg1b.png)
Page 26
Operation
HOUR_THRES
I
Setpoint
Pushing the “Set” key it is possible to access to user’s
Setpoint level. The following table contains the de-
tails of the parameters which is possible to set with
the relevant limitations and default values:
Maintenance alarm
threshod
003X1000h
User’s Setpoints Control of Low Limit High Limit Default
System #1 ON/OFF – OFF ON OFF
System #2 ON/OFF – OFF ON OFF
Cooling Setpoint Inlet 8 20 10
Outlet 6 20 8
Heating Setpoint Inlet 20 48 43
Outlet205045
Glycol setpoint Inlet –15 20 10
Outlet –15 20 8
Band Inlet 1 10 5
Dead band Outlet 1 6 2
Language Selection — ITA ENG GER FRA SPA ITA
Recovery
System #2 ON/OFF — OFF ON OFF
System #1 ON/OFF — OFF ON OFF
Recovery
Setpoint Recovery 30 50 45
Band Recovery 2 6 4
I
Clock Key
To have access to the following mask:
DATE, DAY AND TIME
TIMING PERIODS ENABLING
U:1 Clock
Hour 00:00
Day
Date 00/00/00
Day timing
periods with
setpoint
variations ...........................N
SETPOINTS TIMING
NIGHT SETBACK MODE (*)
(*) Only if this mode is enabled in Service Level.
Setp1 = 00.0 - 00:00h
Setp2 = 00.0 - 00:00h
Setp3 = 00.0 - 00:00h
Setp4 = 00.0 - 23:59h
Night Mode
PM 22:00 AM 06:00
SLS1-en.qxp 29-06-2007 15:37 Pagina 26
