Page 46
Technical data
Electrical data - High Efficiency Unit
(1) The dimensioning of the unit’s power cables is the responsibility of the installer, who shall consider: the rating, the maximum working temperature
in the room, the type of insulation and the cable laying, the maximum length of the power supply line.
SLS HE-LN / HE-ELN 1402 1602 1802 1902 2002 2402 2602 2802
Nominal voltage
V(%)-ph-Hz
400 ±10% / 3 / 50
Nominal power input kW 82 118 136 152 168 187 197 207
Max power input kW 164 184 202 216 230 253 264 275
Nominal current A 146 200 224 254 284 315 333 351
Max. current (FLA) A 262 302 342 360 378 453 469 485
Max. start-up current (LRA) A 391 465 555 652 664 488 515 526
External fuses (A) 315 315 400 400 400 500 500 500
Wire cross area (1) mm
2
240 240 2x120 2x120 2x120 2x185 2x185 2x185
SLS HE-LN / HE-ELN 3002 3202 3402 3602 4202 4602 4802 4804
Nominal voltage
V(%)-ph-Hz
400 ±10% / 3 / 50
Nominal power input kW 209 237 251 265 284 335 352
186,5+186,5
Max power input kW 277 321 342 362 385 446 464
252,5+252,5
Nominal current A 356 405 429 453 486 556 583 315+315
Max. current (FLA) A 490 548 583 618 657 707 757 453+453
Max. start-up current (LRA) A 625 584 663 687 797 904 939 812
External fuses (A) 630 630 800 800 800 800 800 500+500
Wire cross area (1) mm
2
2x240 2x240 2x300 2x300 2x300 2x300 2x300
2x185+2x185
SLS HE-LN / HE-ELN 5204 5604 6004 6404 6804 7204 7804 8404
Nominal voltage
V(%)-ph-Hz
400 ±10% / 3 / 50
Nominal power input kW
196,5+196,5 206,5+206,5
226+226 243+243 264+264 265+265 265+279 313+313
Max power input kW
263,5+263,5 274,5+274,5
301+301 325+325 374+374 362+362 362+380 423+423
Nominal current A 333+333 351+351 379+379 402+402 432+432 453+453 453+476 520+520
Max. current (FLA) A 469+469 485+485 539+539 588+588 618+618 618+618 618+648 648+648
Max. start-up current (LRA) A 861 872 1011 1079 1129 1128 1149 1292
External fuses (A) 500+500 500+500 630+630 630+630 800+800 800+800 800+800 800+800
Wire cross area (1) mm
2
2x185+2x185 2x185+2x185 2x240+2x240 2x240+2x240 2x300+2x300 2x300+2x300 2x300+2x300 2x300+2x300
