Page 68
Technical data
8.6 Service spaces
Units SLS All versions
Installation of Single Units
A and C SCREENED A and B SOLID B and D SCREENED A and B SCREENED A and D SCREENED
B and D SOLID C and D SOLID A and C SOLID C and D SOLID B and D SOLID
A1 A2 A3 A1 A2 A3 A1 A2 A3 A1 A2 A3 A1 A2 A3
Arrangement 1 (m) 2 2 2 2 1.5 1.5 1.5 1.5 1.0 2 1.5 1.5 2
Arrangement2 (m) 2222221.521.51.022222
A wall only may be higher that the units.
The area between the walls must be kept free from any obstacle which may hinder the free air inflow towards the unit(s).
Installation of several Units
mm 2000
mm 2000
mm 2000
mm 2000
WALL A
WALL A
1.5 m
1.5 m
A1
A1 A3A2
A2
2.0 m
1.0 m
1.0 m
WALL C
ARRANGEMENT 1 ARRANGEMENT 2
WALL C
WALL D
WALL D
WALL B
WALL B
2.0 m
2.0 m
1.5 m
mm 3000
SLS2-en.qxp 29-06-2007 15:38 Pagina 68
