Page 74
Spare parts
11 SPARE PARTS
11.1 Spare part list
The table below shows the list of spare parts recom-
mended during the first two years of operation.
Component Number
HP pressure switch 1
Gas filter 2
Thermostatic valve 2
Auxiliary relays 2
Fan’s fuses 6
Compressor’s fuses 6
Auxiliary fuses 6
Set of compressor contactors 1
Fan’s contactor 1
Water sensor 1
Air sensor 1
HP pressure transductor 1
LP pressure transductor 1
Electronic card 1
Keyboard 1
Compressor oil resistor 1
11.2 Oil for compressors
The compressors are lubricated with:
11.3 Wiring diagrams
The wiring diagrams are installed inside the doors of
the electrical panels of the unit. Any request for
wiring diagrams shall be forwarded to Itelco-Indus-
try’s Service Centre.
Compressor
brand
Refrigerant Oil
REFCOMP R134a DEA SE 170
BITZER R134a BITZER BSE 170
