Page 35
Technical data
English
8.2 Technical data
SLS STD-BLN/STD-LN/STD-ELN 1402 1602 1802 1902 2002 2202 2502 2702 3002 3202 3402 3602
Nominal voltage
V/ph/Hz
400-3-50
Number of circuits 222222222222
Number of steps 666666666666
Capacity steps % 25 25 25 25 25 25 25 25 25 25 25 25
Refrigerant
Type R134a
Charge (1) kg
39+39 43+43 50+50 54+54 58+58 59+59 61+61 64+64 68+68 71+71 74+74 78+78
Compressors
Type Screw
Number 222222222222
Start-up type Part-Winding S/D (Star- delta)
Evaporator
Type Shell & Tube
Number 111111111111
Minimum water content l 114 114 162 162 162 162 184 184 222 295 295 295
Condenser
Type Coil type (Al/Cu)
Hydraulic connections
Type Victaulic
Inlet diameter inch 5" 5" 6" 6" 6" 6" 6" 6" 6" 8" 8" 8"
Outlet diameter inch 5" 5" 6" 6" 6" 6" 6" 6" 6" 8" 8" 8"
Weights
Shipping STD-BLN kg 4020 4040 4290 4650 5210 5210 5310 5330 6960 7600 7760 7930
Shipping STD-LN/STD-ELN
kg 4140 4160 4410 4770 5330 5330 5430 5450 7080 7720 7880 8050
Operating STD-BLN kg 4130 4150 4450 4810 5370 5380 5500 5520 7180 7890 8060 8220
Operating STD-LN/STD-ELN
kg 4250 4270 4570 4930 5490 5500 5620 5640 7300 8010 8180 8340
Dimensions
Length mm 4000 4000 4000 4000 4000 4000 4000 4000 6000 6000 6000 6000
Width mm 2200 2200 2200 2200 2200 2200 2200 2200 2200 2200 2200 2200
Height mm 2550 2550 2550 2550 2550 2550 2550 2550 2550 2550 2550 2550
(1) Indicative value. Always refer to the value specified on the unit’s label.
SLS1-en.qxp 29-06-2007 15:37 Pagina 35
