![Airwell SLS 4802 [44/77] English](/views2/1409210/page44/bg2c.png)
Page 43
English
Technical data
8.3 Electrical data - Standard Unit
SLS STD-BLN 1402 1602 1802 1902 2002 2202 2502 2702
Nominal voltage
V(%)-ph-Hz
400 ±10% / 3 / 50
Nominal power input kW 82 118 138 156 174 190 200 210
Max power input kW 164 184 204 220 236 256 267 278
Nominal current A 148 202 230 264 298 324 342 360
Max. current (FLA) A 264 304 348 370 392 462 478 494
Max. start-up current (LRA) A 393 467 560 661 678 497 524 535
External fuses (A) 315 315 400 400 400 500 500 500
Wire cross area (1) mm
2
240 240 2x120 2x120 2x120 2x185 2x185 2x185
SLS STD-BLN 3002 3202 3402 3602 4202 4602 4802 5004
Nominal voltage
V(%)-ph-Hz
400 ±10% / 3 / 50
Nominal power input kW 218 246 260 274 288 343 360 200+200
Max power input kW 286 330 351 371 389 454 472 267+267
Nominal current A 376 425 449 473 497 575 602 342+342
Max. current (FLA) A 510 568 603 638 668 726 776 478+478
Max. start-up current (LRA) A 646 604 683 708 808 923 958 868
External fuses (A) 630 630 800 800 800 800 800 500+500
Wire cross area (1) mm
2
2x240 2x240 2x300 2x300 2x300 2x300 2x300
2x185+2x185
SLS STD-BLN 5404 5704 6004 6404 6804 7204 8404
Nominal voltage
V(%)-ph-Hz
400 ±10% / 3 / 50
Nominal power input kW 210+210 210+235 235+235 246+246 260+260 274+274 288+288
Max power input kW 278+278 278+310 310+310 330+330 351+351 371+371 389+389
Nominal current A 360+360 360+399 399+399 425+425 449+449 473+473 497+497
Max. current (FLA) A 494+494 494+559 559+559 568+568 603+603 638+638 668+668
Max. start-up current (LRA) A 890 985 1051 1016 1120 1169 1290
External fuses (A) 500+500 500+630 630+630 630+630 800+800 800+800 800+800
Wire cross area (1) mm
2
2x185+2x185 2x185+2x240 2x240+2x240 2x240+2x240 2x300+2x300 2x300+2x300 2x300+2x300
(1) The dimensioning of the unit’s power cables is the responsibility of the installer, who shall consider: the rating, the maximum working temperature
in the room, the type of insulation and the cable laying, the maximum length of the power supply line.
SLS2-en.qxp 29-06-2007 15:38 Pagina 43
