Page 36
Technical data
SLS STD-BLN/STD-LN/STD-ELN 4202 4602 4802 5004 5404 5704 6004 6404 6804 7204 8404
Nominal voltage
V/ph/Hz
400-3-50
Number of circuits 2 2 2 4 4 4 4 4 4 4 4
Number of steps 6 6 6 9 9 9 9 9 9 9 9
Capacity steps % 25 25 25 25 25 25 25 25 25 25 25
Refrigerant
Type R134a
Charge (1) kg 86+86 95+95
100+100
61+61/ 64+64/ 64+64/ 68+68/ 71+71/ 74+74/ 78+78/ 86+86/
61+61 64+64 68+68 68+68 71+71 74+74 78+78 86+86
Compressors
Type Screw
Number 2 2 2 4 4 4 4 4 4 4 4
Start-up type S/D (Star- delta)
Evaporator
Type Shell & Tube
Number 1 1 1 2 2 2 2 2 2 2 2
Minimum water content l 462 423 423 184 184
184+222
222 295 295 295 462
Condenser
Type Coil type (Al/Cu)
Hydraulic connections
Type Victaulic
Inlet diameter inch 8" 8" 8" 6" 6" 6" 6" 8" 8" 8" 8"
Outlet diameter inch 8" 8" 8" 6" 6" 6" 6" 8" 8" 8" 8"
Weights
Shipping STD-BLN kg 8210 10820 10850 10620 10660 12290 13910 15190 15520 15850 16420
Shipping STD-LN/STD-ELN
kg 8330 10940 10970 10860 10900 12530 14150 15430 15760 16090 16660
Operating STD-BLN kg 8680 11240 11270 10990 11030 12690 14350 15780 16110 16440 17350
Operating STD-LN/STD-ELN
kg 8800 11360 11390 11230 11270 12930 14590 16020 16350 16680 17590
Dimensions
Length mm 6000 8000 8000 8000 8000 10000 12000 12000 12000 12000 12000
Width mm 2200 2200 2200 2200 2200 2200 2200 2200 2200 2200 2200
Height mm 2550 2550 2550 2550 2550 2550 2550 2550 2550 2550 2550
(1) Indicative value. Always refer to the value specified on the unit’s label.
SLS1-en.qxp 29-06-2007 15:37 Pagina 36
