Technical data
(1) Indicative value. Always refer to the value specified on the unit’s label.
SLS-R STD-BLN/STD-STD-LN/STD-ELN 3002 3202 3402 3602 4202 4602 4802
Nominal voltage
V/ph/Hz
400/3/50
Number of circuits 2222222
Number of steps 6666666
Capacity steps % 25 25 25 25 25 25 25
Refrigerant
Type R134a
Charge (1) kg 68+68 71+71 74+74 78+78 86+86 95+95 100+100
Compressors
Type Screw
Number 2222222
Start-up type Y/∆
Evaporator
Type Shell & Tube
Number 1111111
Minimum water content l 222 295 295 295 462 423 423
Hydraulic connections
Type Victaulic
Inlet diameter inch 6" 8" 8" 8" 8" 8" 8"
Outlet diameter inch 6" 8" 8" 8" 8" 8" 8"
Total heat recovery cond.
Type Shell & Tube
Number 2222222
Minimum water content l 48 48 48 48 48 52 52
Hydraulic connections
Type Gas threaded male type
Inlet diameter inch 4" 4" 4" 4" 4" 5" 5"
Outlet diameter inch 4" 4" 4" 4" 4" 5" 5"
Condenser
Type Coil type (Al/Cu)
Weights
Shipping STD-BLN kg 7710 8350 8520 8680 8970 11830 11860
Shipping STD-LN/STD-ELN
kg 7830 8470 8640 8800 9090 11950 11980
Operating STD-BLN kg 8030 8740 8910 9070 9530 12360 12390
Operating STD-LN/STD-ELN
kg 8150 8860 9030 9190 9650 12480 12510
Dimensions
Length mm 6000 6000 6000 6000 6000 8000 8000
Width mm 2200 2200 2200 2200 2200 2200 2200
Height mm 2550 2550 2550 2550 2550 2550 2550
