Airwell SLS 2702 [42/77] English
![Airwell SLS 6004 [42/77] English](/views2/1409210/page42/bg2a.png)
Page 41
Technical data
English
(1) Indicative value. Always refer to the value specified on the unit’s label.
SLS-R HE-BLN/HE-LN/HE-ELN 1402 1602 1802 1902 2002 2402 2602 2802
Nominal voltage
V/ph/Hz
400/3/50
Number of circuits 22222222
Number of steps 66666666
Capacity steps % 25 25 25 25 25 25 25 25
Refrigerant
Type R134a
Charge (1) kg 40+40 45+45 51+51 56+56 64+64 73+73 75+75 78+78
Compressors
Type Screw
Number 22222222
Start-up type Part-Winding Y/∆
Evaporator
Type Shell & Tube
Number 11111111
Minimum water content l 114 114 162 162 162 184 222 222
Hydraulic connections
Type Victaulic
Inlet diameter inch 5" 5" 6" 6" 6" 6" 6" 6"
Outlet diameter inch 5" 5" 6" 6" 6" 6" 6" 6"
Total heat recovery cond.
Type Shell & Tube
Number 22222222
Minimum water content l 15 17 17 28 32 34 36 36
Hydraulic connections
Type Gas threaded male type
Inlet diameter inch 2"1/2 2"1/2 2"1/2 3" 3" 3" 3" 3"
Outlet diameter inch 2"1/2 2"1/2 2"1/2 3" 3" 3" 3" 3"
Condenser
Type Coil type (Al/Cu)
Weights
Shipping HE-BLN kg 4370 4420 4740 5320 6730 6920 7170 7340
Shipping HE-LN/HE-ELN
kg 4490 4540 4860 5440 6850 7040 7290 7460
Operating HE-BLN kg 4520 4560 4930 5540 6950 7170 7460 7640
Operating HELN/HE-ELN
kg 4640 4680 5050 5660 7070 7290 7580 7760
Dimensions
Length mm 4000 4000 4000 4000 6000 6000 6000 6000
Width mm 2200 2200 2200 2200 2200 2200 2200 2200
Height mm 2550 2550 2550 2550 2550 2550 2550 2550
SLS1-en.qxp 29-06-2007 15:37 Pagina 41
