Page 37
English
Technical data
(1) Indicative value. Always refer to the value specified on the unit’s label.
SLS-R STD-BLN/STD-STD-LN/STD-ELN 1402 1602 1802 1902 2002 2202 2502 2702
Nominal voltage
V/ph/Hz
400/3/50
Number of circuits 22222222
Number of steps 66666666
Capacity steps % 25 25 25 25 25 25 25 25
Refrigerant
Type R134a
Charge (1) kg 39+39 43+43 50+50 54+54 58+58 59+59 61+61 64+64
Compressors
Type Screw
Number 22222222
Start-up type Part-Winding Y/∆
Evaporator
Type Shell & Tube
Number 11111111
Minimum water content l 114 114 162 162 162 162 184 184
Hydraulic connections
Type Victaulic
Inlet diameter inch 5" 5" 6" 6" 6" 6" 6" 6"
Outlet diameter inch 5" 5" 6" 6" 6" 6" 6" 6"
Total heat recovery cond.
Type Shell & Tube
Number 22222222
Minimum water content l 15 17 17 28 28 31 31 31
Hydraulic connections
Type Gas threaded male type
Inlet diameter inch 2"1/2 2"1/2 2"1/2 3" 3" 3" 3" 3"
Outlet diameter inch 2"1/2 2"1/2 2"1/2 3" 3" 3" 3" 3"
Condenser
Type Coil type (Al/Cu)
Weights
Shipping STD-BLN kg 4300 4340 4660 5180 5740 5770 5870 5890
Shipping STD-LN/STD-ELN
kg 4420 4460 4780 5300 5860 5890 5990 6010
Operating STD-BLN kg 4440 4490 4860 5400 5960 6000 6120 6140
Operating STD-LN/STD-ELN
kg 4560 4610 4980 5520 6080 6120 6240 6260
Dimensions
Length mm 4000 4000 4000 4000 4000 4000 4000 4000
Width mm 2200 2200 2200 2200 2200 2200 2200 2200
Height mm 2550 2550 2550 2550 2550 2550 2550 2550
SLS1-en.qxp 29-06-2007 15:37 Pagina 37
