English | 15
Bosch Power Tools 2 609 005 110 | (30.5.11)
Safety Warnings for Drills
f Wear ear protectors when impact drilling. Exposure to
noise can cause hearing loss.
f Use auxiliary handle(s), if supplied with the tool. Loss
of control can cause personal injury.
f Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord. Cutting ac-
cessory contacting a “live” wire may make exposed metal
parts of the power tool “live” and could give the operator an
electric shock.
f Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility company
for assistance. Contact with electric lines can lead to fire
and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.
f Switch off the power tool immediately when the tool in-
sert jams. Be prepared for high reaction torque that
can cause kickback. The tool insert jams when:
— the power tool is subject to overload or
— it becomes wedged in the workpiece.
f Hold the machine with a firm grip. High reaction torque
can briefly occur while driving in and loosening screws.
f When working with the machine, always hold it firmly
with both hands and provide for a secure stance. The
power tool is guided more secure with both hands.
f Secure the workpiece. A workpiece clamped with clamp-
ing devices or in a vice is held more secure than by hand.
f Always wait until the machine has come to a complete
stop before placing it down. The tool insert can jam and
lead to loss of control over the power tool.
Products sold in GB only: Your product is fitted with a
BS 1363/A approved electric plug with internal fuse (ASTA
approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an author-
ised customer service agent. The replacement plug should
have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains sock-
et elsewhere.
Products sold in AUS and NZ only: Use a residual current de-
vice (RCD) with a rated residual current of 30 mA or less.
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Intended Use
The machine is intended for impact drilling in brick, concrete
and stone as well as for drilling in wood, metal and plastic. Ma-
chines with electronic control and right/left rotation are also
suitable for screwdriving and thread-cutting.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Depth stop*
2 Keyless chuck
3 Button for depth stop adjustment *
4 “Drilling/Impact Drilling” selector switch
5 Thumbwheel for electronic speed preselection
(PSB 750 RCE/PSB 750 RCA)
6 Lock-on button for On/Off switch
7 Rotational direction switch
8 On/Off switch
9 Auxiliary handle (insulated gripping surface) *
10 Wing bolt for adjustment of auxiliary handle *
11 Extraction device with dust collector *
12 Dust collector*
13 Level indicator of the dust collector *
14 Thumbwheel for speed preselection
(PSB 650 RE/PSB 6500 RE/PSB 650 RA)
15 Handle (insulated gripping surface)
16 Release button for dust collector *
17 Filter element (Microfilter System) *
18 Rubber gasket for dust collector *
19 Dust protection ring*
20 Release button for extraction device *
21 Clamp for extraction device*
22 Locking latch for dust collector*
23 Universal bit holder*
24 Screwdriver bit*
25 Spindle lock button
(PSB 650 RE/PSB 6500 RE/PSB 650 RA)
26 Allen key **
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
**Commercially available (not included in the delivery scope)
OBJ_DOKU-27001-001.fm Page 15 Monday, May 30, 2011 8:03 AM
