Gigabyte GA-8IGX [12/95] Chapter 2 hardware installation process
![Gigabyte GA-8IGX [12/95] Chapter 2 hardware installation process](/views2/1047312/page12/bgc.png)
8
GA-8IGX Motherboard
To set up your computer, you must complete the following steps:
Step 1- Install the Central Processing Unit (CPU)
Step 2- Install memory modules
Step 3- Install expansion cards
Step 4- Connect ribbon cables, cabinet wires, and power supply
Step 5- Setup BIOS software
Step 6- Install supporting software tools
Chapter 2 Hardware Installation Process
Step 2
Step 4
Step 3
Step 4
Step 4
Step 1
