GA-8IGX Motherboard
42
Frequency/Voltage Control
Figure 8: Frequency/Voltage Control
CMOS Setup Utility-Copyright (C) 1984-2002 Award Software
Frequency/Voltage Control
CPU Clock Ratio 15X Item Help
CPU Host Clock Control Disabled Menu Level
x CPU Host Frequency (Mhz) 100
x PCI/AGP Divider Disabled
Host/DRAM Clock ratio Auto
Memory Frequency (Mhz) 266
PCI/AGP Frequency (Mhz) 33/66
DIMM OverVoltage Control Normal
AGP OverVoltage Control Normal
CPU Voltage Control Normal
Normal CPU Vcore 1.750V
: Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F3: Language F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
&&
&&
&CPU Clock Ratio
Set CPU Ratio if CPU Ratio is unlocked.
10X~24X It’s depends on CPU Clock Ratio.
&&
&&
&CPU Host Clock Control
Note: If system hangs up before enter CMOS setup utility, wait for 20 sec for times out reboot . When
time out occur, system will reset and run at CPU default Host clock at next boot.
Disable Disable CPU Host Clock Control.(Default value)
Enable Enable CPU Host Clock Control.
&&
&&
&CPU Host Frequency
100MHz ~ 355MHz Set CPU Host Clock from 100MHz to 355MHz.
