Gigabyte GA-8IGX [75/95] Revision history

Appendix

Revision History

Appendix B: RealTek AC’97 Audio Driver

(2)

Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver

CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device

icon in "My computer", and execute the setup.exe.

(1)

2.Click "Next".

(3)

3.Click "Finish" to restart computer.

(4)

1.Click "RealTek AC’97 Audio Driver"

item.

Press "Audio" icon.
