22
GA-8IGX Motherboard
J) F_PANEL (2x7 pins jumper)
HD (IDE Hard Disk Active LED) Pin 1: LED anode(+)
Pin 2: LED cathode(-)
SPK (Speaker Connector) Pin 1: VCC(+)
Pin 2- Pin 3: NC
Pin 4: Data(-)
RST (Reset Switch) Open: Normal Operation
Close: Reset Hardware System
PD+/PD_G-/PD_Y-(Power LED) Pin 1: LED anode(+)
Pin 2: LED cathode(-)
Pin 3: LED cathode(-)
PW (Soft Power Connector) Open: Normal Operation
Close: Power On/Off
Please connect the power LED, PC speaker, reset switch and power switch etc of your chassis front
panel to the F_PANEL connector according to the pin assignment above.
PD_Y-
PW-
1
RST+
HD+
SPK-
13
HD-
PD_G-
PD+
PW+
SPK+
RST-
14
2
1
1
Q) NB_FAN (Chip Fan)
1
GND
+12V
Please note:
If installed wrong direction, the Chip Fan will not
work. Sometimes will damage the Chip Fan.
(Usually black cable is GND)
