GA-8IGX Motherboard
32
Integrated Peripherals
Figure 4: Integrated Peripherals
CMOS Setup Utility-Copyright (C) 1984-2002 Award Software
Integrated Peripherals
On-Chip Primary PCI IDE Enabled Item Help
On-Chip Secondary PCI IDE Enabled Menu Level
IDE1 Conductor Cable Auto If a hard disk
IDE2 Conductor Cable Auto controller card is
USB Controller Enabled used, set at Disable
USB Keyboard Support Disabled
USB Mouse Support Disabled [Enabled]
AC97 Audio Auto Enable onboard IDE
Onboard LAN Chip Enabled PORT
Onboard LAN Boot ROM Disabled
Onboard Serial Port 1 3F8/IRQ4 [Disabled]
Onboard Serial Port 2 2F8/IRQ3 Disable onboard IDE
UART Mode Select Normal PORT
x UR2 Duplex Mode Half
Onboard Parallel Port 378/IRQ7
Parallel Port Mode SPP
x ECP Mode Use DMA 3
Game Port Address 201
Midi Port Address 330
Midi Port IRQ 10
CIR Port Address Disabled
x CIR Port IRQ 11
: Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F3: Language F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
