Gigabyte GA-8IGX [40/95] Cir port address

GA-8IGX Motherboard

300 Set Midi Port Address to 300.

330 Set Midi Port Address to 330.(Default Value)

Disabled Disable this function.

&Midi Port IRQ

5 Set Midi Port IRQ to 5.

10 Set Midi Port IRQ to 10. (Default Value)

&CIR Port Address

310 Set CIR Port Address to 310.

320 Set CIR Port Address to 320.

Disabled Disable this function. (Default Value)

&CIR Port IRQ

5 Set CIR Port IRQ to 5.

11 Set CIR Port IRQ to 11. (Default Value)
