GA-8IGX Motherboard

A-3. Intel 845G Chipset VGA Graphics Driver

(1)

(2)

(3)

Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver

CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device

icon in "My computer", and execute the setup.exe.

2.Click "Next".

3.Click "Yes".

(4)

1.Click "Intel 845G Chipset VGA

Graphics Driver" item.
