Gigabyte GA-8IGX [76/95] Appendix c intel 82562 network driver

GA-8IGX Motherboard

¾ For your reference, you can use the

followingsteps to complete the Network Driver

Installation.

Appendix C: Intel 82562 Network Driver

(1)

1.Click "Driver Information" item.

Press "Network" icon.

(2)

1.Click "My Computer"

“Properties”.

(3)

(4)

2.Click "Hardware"”Device Manager”.

3.Click "Other devices""Ethernet

Controller".

(5)

4.Click "Reinstall Driver”.

5.Click "Next".

(6)
