Switching Configuring Ports
User Guide
33
LAG Displays the LAG which the port belongs to.
2) Click Apply.
Note:
•
It is recommended to set the ports on both ends of a link with the same speed and duplex
mode.
•
Keep the port that is connected to the management device enabled, or you cannot access the
switch.
•
The parameters of the port members in a LAG should be set as the same.
