User Guide 4
Getting Started Introduction
1
Introduction
The Easy Smart Configuration utility allows users to centrally configure the Easy Smart
Switches in the entire network. In this part, we will introduce how to install the utility
software and discover switches.
You can also configure Easy Smart Switches individually on their web management
page. For more details, refer to the User Guide of the products at Download Center at
https://www.tp-link.com/support
.
