User Guide 68
Configuring QoS Configuring Bandwidth Control
Note:
•
For a port, the ingress rate control feature and the storm control feature cannot be enabled
at the same time. If you enable ingress rate control for a port, storm control will be disabled
for that port automatically.
•
When egress rate is set for one or more ports, it is recommended to disable the flow control
on each port to ensure the switch works normally.
•
For ports in the same LAG, bandwidth control should be configured the same to ensure a
successful port aggregation.
