![Deca MACH 119 [5/36] Charging a battery](/views2/1547191/page5/bg5.png)
4
950503-07 10/09/14
Never use the battery charger with damaged cables or
whenever the charger has been subjected to impact or
damaged.
Never dismantle the battery charger: take it to an authorized
service centre.
Supply cable must be replaced by qualied people.
Never position the battery charger on ammable surfaces.
Never place the battery charger and its cables in the water
or on wet surfaces.
Position the battery charger with adequate ventilation; never
cover it with other objects or close it inside containers or
closed shelves.
Connection of battery charger
Before starting the battery charger, make sure that the
battery voltage selected is the right one. Incorrect battery
voltage can damage objects and injure people.
To protect the electronic components on the vehicle,
carefully read the instructions by the car manufacturer
and the battery manufacturer before charging a battery
or using the Quick start procedure.
¾ Connect red charging clamp to positive (+) battery terminal and
black charging clamp (-) to negative battery terminal.
¾ If the battery is installed on a motor vehicle, rst connect
the clamp to the battery terminal that is not connected to
the bodywork. Afterwards, connect the second clamp to the
bodywork at a point far from both the battery and the petrol
pipes.
¾ Plug the plug into the socket to begin charging.
¾ To break off charging disconnect rst the mains supply, then
remove charging clamp from car body or negative terminal
(-) and charging clamp from positive terminal (+)
Charging a battery
¾ Set [6/12V] [12/24V]** to match voltage of battery to be
charged.
¾ Set [MIN/MAX]** to desired position: Max = fast charge;
Min = slow charge.
The ammeter may not indicate any value if the charger is set
to Min and is connected to a well charged battery
During charging of the battery, the rate of charge, shown on
the ammeter will slowly fall until it remains at a steady value
(never zero), indicating that the battery is charged.
L The charging current absorbed by a battery recharging
depends on the state of the battery itself. For models
with charge settings, select the charging current
nearest to 10% of the capacity of the battery for
charging. (ex. I=4 Amps. for a battery of 40 Amp/h.).
Make sure that the battery capacity (Ah) is not less than
that indicated on the battery charger (C-Min)
L Once a battery is charged and bubbles form in the liquid
electrolyte, it is advisable to end the charging so that the
battery does not get damaged.
Charging sealed MF, GEL, AGM batteries
You cannot reach the liquid electrolyte in a sealed battery. Do
not overcharge batteries and so you will protect the battery
life.
Slow charge; frequently check voltage at the battery terminals
by means of a regular tester.
Stop charging when voltage reaches 14.4 Volt for 12-Volt
batteries; 7.2 Volt for 6-Volt batteries; 28.8 Volt for 24-Volt
batteries.
The battery charger is not tted with an automatic
charge stop and must be disconnected once charge is
completed so as not to damage the battery.
Safety fuse that protects against short circuits and
reverse polarity.**
This fuse interrupts the electric circuit every time there is
surcharge caused by a short circuit at the clamps or the
battery cells, or by reverse polarity at the battery terminals (+;
-).
Always make sure that the polarity is correct so as not
to injure people or damage things.
Disconnect the battery charger from the mains before
replacing fuses.
L The appliance is equipped with a thermostatic cut-out with
automatic reset which is tripped in case of thermal overload
to protect the device against any overheating.
** These functions may not be included in some models.
FR
Notice d’utilisation.
Chargeur de batterie
ÉTIQUETTE D’AVERTISSEMENT Fig.1.
Avantlapremièremiseenservice,xer
l’autocollant fourni dans votre langue sur le
chargeur de batterie.
Avant de charger les batteries, lisez
attentivement le contenu de ce manuel.
Lisez la notice de la batterie et du véhicule
correspondant.
Généralités et avertissements
L’appareil peut être utilisé par des enfants d’un âge non
inférieur à 8 ans et par des personnes ayant des capacités
mentales, physiques ou sensorielles réduites ou ayant un
manque d’expérience et de connaissance, seulement si
elles sont supervisées ou bien instruites de façon appropriée
sur l’utilisation sûre de l’appareil et après avoir compris les
dangers éventuels.
Les enfants ne doivent pas effectuer le nettoyage et l’entretien
sans surveillance.
Le chargeur de batteries est adapté uniquement à la charge
de batteries “plomb/acide” du type:
D Batteries “WET”: scellées avec à l’intérieur un liquide
électrolytique : à faible maintenance ou bien sans
maintenance (MF), “AGM”, “GEL”.
N’essayez pas de recharger des batteries non rechargeables
ou des batteries autres que celles prévues.
Ne rechargez pas les batteries gelées car elles pourraient
exploser.
Uniquement pour utilisation à l’intérieur.
ATTENTION GAZ EXPLOSIFS !
La batterie crée du gaz explosif (hydrogène) durant le
fonctionnement normal et en quantité supérieure durant le
chargement.
