Getting started

The delivery package contains the following items:

 RFDT-02 hardware and PC cables

 Battery charger

 Battery charger mains (AC power) cable

 Set of plugs

 User’s Guide

 DriveConfig CD

 Six spare pin headers

 20 pcs notification stickers for parameterization.

More spare pin headers and notification stickers for parameterization can be

ordered. Contact your local ABB office.

Assembling the spare pin headers

Figure 2. Replacing the spare pin header

Note: Switch off the DriveConfig before proceeding.

Assemble the pin header as shown in the Figure 2. Check correct polarization.

Please note that the pin header fits in the wand bottom plastic only one way.
