Drive monitoring
Dialog Item
Meaning
Min Y-axis
Minimum Y-axis value. In Auto Y-axis mode the value for
Y-axis minimum is the smallest minimum value of the
monitored parameters.
Note: The negative Y-axis values are limited to be over
-200 000.
Amount of Samples
The number of samples stored in the RAM. The value
should be between 1 000 and 1 000 000.
X-axis length
The length of the X-axis in seconds.
Enable Point Marks
Show point marks to represent actual samples in the
trend lines.
Table 7. Signal-specific monitoring settings
Dialog Item
Meaning
Select
Select a maximum of four signals for monitoring.
Monitoring signals are selected with the parameter
subset selection dialog.
Manual Coefficient
Set the coefficient value for the signal selected in the
drop down list. The actual sample values received from
the drive are multiplied by this value. Coefficients can be
used to scale signals in order to improve clarity.
Auto Coefficient
The coefficients are calculated automatically based on
the maximum values of the monitored signals and the
maximum value of the Y-axis.
Note: Auto coefficients are calculated when the
Monitoring Settings window is closed.
Note: Manual or Auto Coefficient selection is the same
for all monitored signals. Only the actual coefficients are
signal-specific.
Monitor Stopping
Monitoring can be stopped manually with the button in
the Monitor Toolbar or automatically when the defined
stopping condition is reached.
After conditions
You can define the stopping condition separately for
each of the signals. The monitoring is stopped if any of
the stopping conditions is true. You can also define the
monitoring to continue for certain duration after reaching
the stopping condition.
File operations
To save the monitoring data to a DriveConfig Monitoring (DCM) file, select File -
Save.
To load a DCM file, select File - Open.
Note: The Monitor window must be active when saving or loading the monitor data.
