28
Parameters
Figure 14. Transfer dialog
Note: One Parameter Browser window can contact only one drive.
Table 3. Parameter function buttons
Icon
Function
Open parameter file
Save parameter file
Read parameters from drive
Transfer parameters to drive
Figure 15. Parameter buttons
Compare parameters
To compare parameters in the active Parameter Browser window with another
Parameter Browser window or a DriveConfig Parameter (DCP) file, select
Parameter Browser – Compare parameters with...
The Compare Parameters – Selection dialog appears.
