46
Error messages
Files
Commissioning wizard-related error messages are listed in the following table.
Table 13. Commissioning wizard-related error messages
Error message
Cause
Solution
The parameter file does not contain valid
header, and therefore file can not be opened.
The .dcp file you are trying to
open is corrupted or created by
another application.
Change to online mode and try
again.
Unable to open .ini file.
No matching .ini file in
DriveConfig.
Check that there is acs55.ini file
in directory '…\DriveConfig'.
Loaded file and active parameter browser
version numbers differs. Differences are the
following:
File information - Drive: (file name), Software
revision: xxx and Size class: xxx
Parameter browser - Drive: (browser name),
Software revision: xxx and Size class: xxx Do
you want to download changes to the drive?
You have opened the parameter
file which has different software
version or size class than in
drive you are connected to.
Parameters can be transferred
to drive.
Monitor
Monitoring-related error messages are listed in the following table.
Table 14. Monitoring-related error messages
Error message
Cause
Solution
Start of drive monitoring is not possible in Offline
mode.
No communication between the
drive and DriveConfig.
Check the connection to the
drive and communication
settings and try again.
