Loading drive firmware
Loading drive firmware
What this chapter contains
This chapter instructs in loading the firmware to the drive.
Loading the firmware
Note: Before loading the firmware, check that the .dlt files have been stored in the
correct directory in the directory where DriveConfig has been installed:
DriveWare\DriveConfig\ACS55
1. To load firmware to the drive, select Drive – Transfer firmware from file.
2. Locate the file and click Open. Upgrading starts immediately after selecting
the new firmware package.
3. Load the file to the drive following the instructions given for transferring the
parameter file. For instructions, see section Handling parameter files on
page 26.
Note: Power-off is not needed when ACS55 has factory-installed firmware version
2200. However, upgrading the firmware from version 2010 to 2200 requires power-
off.
